Jet Filter

The Jet Filter is designed to separate air-dust mixture, to retain dust and discharge clean air through the stack. It enables to discharge air from flour which is generally transported by air with pneumatic systems or from internal systems, and filters molecules carried with the air current, and retains them in the system.

MODEL A ØB ØC DxE FxG X X1 Y Z Z1 W T
ASK-F- 8T 2000 750 350 250x145 350x250 700 - - 160  - - -
ASK-F- 10T 2000 1000 400 400x215 400x350 1190 - - 160  - - -
ASK-F- 26T 2000 1140 500 500x270 500x470  1330 730 550  160  600 230 250
ASK-F- 39T 2400 1340 500 650x300 500x470 1570 985 550  160  600 230 250
ASK-F- 52T 2400 1500 600 750x350  650x470 1870 1030 550  160  600 230 250
ASK-F- 78T 2400 1840 600 800x500 650x470 2430 1790 550  160  600 230 250
ASK-F- 104T 2400 2002 700 800x500 700x470 2600 1980 550  160  600 230 250
